Full extension, face frame undermounted slide
Soft closing & push to open, 2 function combine together
Lock connected design, fast release structure
3D adjustment include height, width and depth
With plastic or metal rear bracket optional
With synchronized bar (optional)

This innovative S42 full extension push open soft closing face frame slide combines the convenience of push-to-open functionality with the smooth and controlled closing of soft closing technology. With its full extension capability, it provides maximum access to drawer contents. The lock connected design and fast release structure make installation easily. Additionally, it offers 3D adjustment options for height, width, and depth, ensuring a perfect fit for any application. For enhanced drawer movement, an optional synchronization rod is also available.

Product	S42H800	S42P800
Function	Soft closing	Push to open & soft closing
Loading capacity	35kg	35kg
Length	305-610mm	381-610mm
Drawer height adjustment	0~+3mm	0~+3mm
Drawer width adjustment	±1.5mm	±1.5mm
Drawer depth adjustment	0~+5mm	+4~-2mm
Country of origin	China	China
